PJMAX-OUT HD4

● 4 high-speed RJ45 output connectors, 4 6-PIN phoenix connectors.
● Support videowall signal processing function.
● Maximum transmission distance can up to 100M with CAT5e/6 cable.
● Support Hot-swap function; Support synchronized switching of audio and video signals; Support AUTO DELAY.
● Support EDID Reading function.
● Compatible with H-CAT protocol.
● Support 4 H-CAT seamless outputs, the RS-232 and IR connectors are embed on card.
● The maximum output resolution can up to 1920*1200@60Hz when cooperated with CR-UCAT5 HDMI 4KR, and transmitting distance can be up to 100m.
● Supply power to distant transmitters with an optional POC power supply.
